Technical Workshop / HPFP rear internals pictures
« Last post by Shottyman on Today at 06:01:10 pm »I've just brought an 06 plate GTI (200hp) and after doing a bit of research decided that along with a service, I would change the PCV and the HPFP cam follower.
I knew where it was, I'd had a quick look at the posts about how to change the follower so I cracked on, big mistake, now I've messed up the banjo bolt but that's no biggie I can just get a new one for a couple of quid, easy fix. Unfortunately I took the wrong bolts out of the HPFP at first, I took the 2 smaller Torx Star bits out then realising I needed to take the larger Torx ones out removed them too, tilted the pump up and all the internals from the sensor end fell out
. A spring type washer, a diaphragm style item, and a couple of other washers.
Has anyone got an old pump they can kind of take to bits and show me the orientation of these components, I really don't want to have to buy a new pump. I mean I think I've put it back together correctly, it runs and its not giving me any faults but there's a ticking noise from the HPFP area and I cant remember if it was there beforehand or not
feel free to call me a muppet
I knew where it was, I'd had a quick look at the posts about how to change the follower so I cracked on, big mistake, now I've messed up the banjo bolt but that's no biggie I can just get a new one for a couple of quid, easy fix. Unfortunately I took the wrong bolts out of the HPFP at first, I took the 2 smaller Torx Star bits out then realising I needed to take the larger Torx ones out removed them too, tilted the pump up and all the internals from the sensor end fell out
. A spring type washer, a diaphragm style item, and a couple of other washers.Has anyone got an old pump they can kind of take to bits and show me the orientation of these components, I really don't want to have to buy a new pump. I mean I think I've put it back together correctly, it runs and its not giving me any faults but there's a ticking noise from the HPFP area and I cant remember if it was there beforehand or not
feel free to call me a muppet
